Troubleshooting
Table 4-6: Diagnostics error codes (cont.)
Error code Error log message
Possible defect
on board Note
122000001
HwDiagWaveformMemory channel=2,
MemoryController-P Address Bus Error
Address=0xXXXXXXXX RAM/PLD-pinName
expected data=xxxxxxxx actual data=xxxxxxxx P:
PLD number RAM/PLD-pinName:U5x0yy-pinRam /
U400zz-pinPld
AWG12G
P=0 -> U400PB, U500PB, U510PB
P=1 -> U400QB, U500QB, U510QB
P=2 -> U400RB, U500RB, U510RB
P=3 -> U400SB, U500SB, U510SB
P=4 -> U400TB, U500TB, U510TB
122000002
HwDiagWaveformMemory channel2,
MemoryController-P Cell HL Error P: PLD
number HL: U5x0yy
AWG12G
P=0 -> U500PB, U510PB P=1 ->
U500QB, U510QB P=2 -> U500RB,
U510RB P=3 -> U500SB, U510SB
P=4 -> U500TB, U510TB
122000003
HwDiagWaveformMemory channel=2,
MemoryController-P Invert Bit bus RAM/PLD-pinName
testNo-testCnt Error expected data=xxxxxxxx
actual data=xxxxxxxx P: PLD number
RAM/PLD-pinName:U5x0yy-pinRam / U 400zz-pinPld
testNo:1’st or 2’nd testCnt:1’st - 4’th
AWG12G
P=0 -> U400PB, U500PB, U510PB
P=1 -> U400QB, U500QB, U510QB
P=2 -> U400RB, U500RB, U510RB
P=3 -> U400SB, U500SB, U510SB
P=4 -> U400TB, U500TB, U510TB
130000000
HwDiagClockRegister PLL_MUX_HIGH=0 AWG12G,
CLK12G
AWG12G: U1000 CLK12G: U3200
130000001
HwDiagClockRegister P LL_MUX_LO W=1 AWG12G,
CLK12G
AWG12G: U1000 CLK12G: U3200
131000000
HwDiagClockPll 7.5GHz YIG tuning error AWG12G,
CLK12G
AWG12G: U1000, U1040 CLK12G:
U3200, U3250, Y3100, Y3280
131000001
HwDiagClockPll 7.5GHz PLL Unlocked AWG12G,
CLK12G
AWG12G: U1000, U1040 CLK12G:
U3200, U3250, Y3100, Y3280
131000002
HwDiagClockPll 1GHz PLL Locked AWG12G,
CLK12G
AWG12G: U1000 CLK12G: U3200
131000003
HwDiagClockPll 4.9GHz YIG tuning error AWG12G,
CLK12G
AWG12G: U1000, U1040 CLK12G:
U3200, U3250, Y3100, Y3280
131000004
HwDiagClockPll 4.9GHz PLL Unlocked AWG12G,
CLK12G
AWG12G: U1000, U1040 CLK12G:
U3200, U3250, Y3100, Y3280
131000005
HwDiagClockPll 10.1GHz YIG tuning error AWG12G,
CLK12G
AWG12G: U1000, U1040 CLK12G:
U3200, U3250, Y3100, Y3280
131000006
HwDiagClockPll 10.1GHz PLL Unlocked AWG12G,
CLK12G
AWG12G: U1000, U1040 CLK12G:
U3200, U3250, Y3100, Y3280
140000000
The error occurred in the EEPROM read. 1st=FST
2nd=SND FST: the data that is received from EEPROM
at the first read check SND: the data that is received
from EEPROM at the second read check, which is
implemented after writing 0x55 to EEPROM
OUT10G OUT10G-CH1: U 500, U550
140000001 Message varies depending on the situation.
OUT10G OUT10G-CH1: U 500, U550
1410P0001
Analog Level Diag CH1 positive (negative) 5db
attenuator failed. expected 0.56234, actual xxxxx
OUT10G OUT10G: K610, K710
4–60 AWG7000B and AWG7000C Series Service Manual
