Tektronix AWG7000B Series

Replaceable Parts
Table 5-19: Rep
laceable parts list – AWG12G module
Fig. &
index
number
Tektronix
part
number Model
Serial no.
effective
Serial no.
discont’d Qty Name & description
5-19-
AWG12G MODULE
-1 352-1114-00 1
HOLDER; CABLE RETENTION SMA,PORON URETHANE,
FORMATCHEDPAIRRFCABLE,AWG
174-5341-00
AWG7xx1B
2
CABLE ASSY ELEC: RF,COAX,8IN L,50 OHM,SMP-R RTA,
SMP-R RTA, W/LABEL, MATCHED DELAY FLEX COAX
CABLE
-2
174-5341-00
AWG7xx2C
AWG7xx2B
4
CABLE ASSY ELEC: RF,COAX,8IN L,50 OHM,SMP-R RTA,
SMP-R RTA, W/LABEL, MATCHED DELAY FLEX COAX
CABLE
174-5340-00
AWG7121B
Option 02
1
CABLE ASSY ELEC: RF,COAX,8IN L,50 OHM,SMP-R RTA,
SMA-P STR, W/LABEL, MATCHED DELAY FLEX COAX
CABLE
-3
174-5340-00
AWG7122C
Option 06
AWG7122B
Option 06
2
CABLE ASSY ELEC: RF,COAX,8IN L,50 OHM,SMP-R RTA,
SMA-P STR, W/LABEL, MATCHED DELAY FLEX COAX
CABLE
-4 343-1701-00 1
CLAMP,CABLE; WITH ADHESIVE BACK
174-5342-00
AWG7xx1B
1
CABLE ASSY ELEC: RF,COAX,8IN L,50 OHM,SMP-R RTA,
SMP-R RTA, W/LABEL, MATCHED DELAY FLEX COAX
CABLE
-5
174-5342-00
AWG7xx2C
AWG7xx2B
2
CABLE ASSY ELEC: RF,COAX,8IN L,50 OHM,SMP-R RTA,
SMP-R RTA, W/LABEL, MATCHED DELAY FLEX COAX
CABLE
174-5249-00
AWG7xx1B
1
CABLE ASSY ELEC: 1 X 16P,6.5IN L,AWG24 X 16,
PHR-16,PHR-16,JST
-6
174-5249-00
AWG7xx2C
AWG7xx2B
2
CABLE ASSY ELEC: 1 X 16P,6.5IN L,AWG24 X 16,
PHR-16,PHR-16,JST
-7
352-0482-00 1
HOLDER,CABLE TIE; 0.75 SQ,STICKY BACK,PLASTIC,
SAFETY CONTROLLED
-8 343-0549-00 1
STRAP,TIEDOWN; 0.098 W X 4.0 L, ZYTEL
-9 664-6421-02
AWG7xx2B
AWG7xx2C
1
CIRCUIT BOARD ASSY; AWG12G,2CHANNEL
GENERATOR, 389-4020-XX WIRED
AWG7000B and AWG7000C Series Service Manual 5–35
