Replaceable Parts
Table 5-12: Rep
laceable parts list – AWG7000B series power s upply assembly
Fig. & index
number
Tektronix
part number
Serial no.
effective
Serial no.
discont’d Qty Name & descrip
tion
5-12-
POWER SUPPLY ASSEMBLY
-1 119-6986-03 1
POWER SUPPLY; AC-DC;460W;+3.3V 40A,+5V 34A,+12V 25A,
-12V 1A,+5VSB 2A;90-264VAC,47-63HZ;BERG 51624-XX001;
9.5X4.9X3.8
IN,SAFETY CONTROLLED
-2 211-1050-00 6
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
-3 407-5145-0
1
1
BRACKET, POWER SUPPLY
-4 211-1050-00 3
SCREW,MACH
INE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
-5
174-5269-00 1
CABLE ASSY; AC INLET TO CKT BD,14 IN L,AWG16 X 3,
W/FN9222-
10/06 FILTER/1-480700 CONN
-6 211-1050-00 4
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
-7
407-5369
-00
1
BRACKET, SUPPORT; ANTI-SHOCK, DUMMY POWER SUPPLY, .063
ALUMINUM WITH 2 SORTS OF ABSORBERS ATTACHED
(AWG7000
B SERIES ONLY)
-8 211-1050-00 4
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
(AWG700
0B SERIES ONLY)
5–22 AWG7000B and AWG7000C Series Service Manual
