Tektronix AWG7000B Series

Replaceable Parts
Table 5-22: Rep
laceable parts list – rear connectors
Fig. & index
number
Tektronix
part number
Serial n o.
effective
Serial no.
discont’d Qty N ame & descrip
tion
5-22-
REAR CONNECTOR
-1 174-5323-01 1
CABLE ASSY ELEC: RF,COAX,50 OHM,9.5IN L,SMA-R STR PANEL
MOUNT TO SMP-R RTANG,FLEX COAX CABLE
-2 131-8054-00 2
CONN,RF,JACK; BNC,PNL,50 OHM,FEMALE,STR,PELTOLA/PNL MNT,
SILVER ALLOY, 0.576 MLG X 0.366 TERMN,0.375-32 THD, D-FLAT
-3 174-5294-0
0
2
CABLE ASSY ELEC: RF,COAX,7IN L,50 OHM,SMA-P STR,PELTOLA,
FLEX COAX CABLE
-4 174-5680-0
0
1
CABLE ASSY ELEC: EVENT, 7.88IN L,BOARD TO REAR PANEL,15P
EVENT CONN TO 16P HEADER CONN, SAFETY CONTROLLED
(AWG7000C
SERIES)
-5
214-3903-00 2
SCREW, JACK; 4-40 X 0.312 LONG, 0.188 H HEX HEAD STAND OFF,
4-40 INT T
HD, X 0.312 THD EXT 4-40, STEEL, ZINC PLATED
(AWG7000C SERIES)
-6 276-0424-00 1
CORE,EMI
; EMI SUPPRESSION FERRITE;SPLIT ROUND CABLE,IMPE
360 OHM AT 300MHZ, .357 MAX CABLE, STEWARD PN 28A2736-0A2
(AWG7000C SERIES)
AWG7000B and AWG7000C Series Service Manual 5–41
