Removal and Installation Procedures
Removal and Installation Procedures
This section contains procedures for removal and installation of all mechanical
and electrical modules.
Preparation
WARNING. Only qualiļ¬ed personnel should perform service procedures.
Before performing this or any other procedure in this manual, read the General
Safety Summary and Service Safety Summary found at the beginning of this
manual. To prevent possible injury to service personnel or damage to the
instrument components, read Preventing ESD in this section.
This section contains the following items:
This preparatory information that you need to properly do the following
procedures.
List of tools required to remove and disassemble all modules.
Procedures for removal and reinstallation of the modules.
WARNING. Before doing any procedure in this section, disconnect the power cord
from the line voltage source. Failure to do so could cause serious injury or death.
NOTE. Read Equipment Required for a list of the tools needed to remove and
install modules in this instrument. (See page 4-8, Required Equipment.) Read the
cleaning procedure before disassembling the instrument for cleaning.
Ad
justment After Repair
After the removal and replacement of a module due to electrical failure, perform
the adjustment procedures. (See page 3-1, Adjustment Procedures.)
List of Modules
The Replaceable Parts s ection provides a list of all replaceable modules.
4ā6 AWG7000B and AWG7000C Series Service Manual
