Tektronix AWG7000B Series

Replaceable Parts
Table 5-7: Repl
aceable parts list – AWG7000C Series drive modules
Fig. & index
number
Tektronix
part number
Serial no.
effective
Serial no.
dis-cont’d Qty Name & descrip
tion
5-7-
DRIVE MODULE
-1 407-5156-00 1
BRACKET,DVD-CD/RW;ADAPTER FOR DVD-CD/RW SLIMLINE
-2 211-1050-00 2
SCREW,MACHI
NE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
-3 211-0950-00 4
SCREW,MACHINE; M2X.4X3L,PHL, PNH, STL NI PL
-4 119-7473-0
0
1
DISK DRIVE; OPTICAL, CD-RW/DVD ROM OR COMBO, SATA,
DW224SV93;SAFETY CONTROLLED
-5
174-5650-0
0
1
CABLE, SATA-DVD, DATA AND POWER, SAFETY CONTROLLED
-6 441-2474-03 1
CHASSIS;DR
IVE BAY;METAL
-7
211-1050-00
7
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
-8 174-5349-
00
1
CABLE ASSY; SATA COMBO, HARD DRIVE CABLE WITH LATCH
-9 407-5337-00 1
BRACKET,
RHDD; SATA COMBO CABLE RETENTION
-10 211-1050-00 2
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
-11 650-5336
-00
1
ACCESSORY KIT; REMOVABLE HARD DRIVE ASSEMBLY, V4.0
PROGRAMMED FW
-12 351-111
8-00
1
GUIDE,HD; REMOVABLE,3.5 INCH HARD DISK DRIVE, SAFETY
CONTROLLED
-13 211-11
74-00
4
SCREW,MACHINE; W/HEAVY PATCH THREADLOCKING M ATERIAL;
6-32 X 0.312 L,PNH,STL CAD PLT,T15
-14 407-53
31-00
1
BRACKET, ASSEMBLY, REMOVABLE 3.5 INCH HARD DRIVE
CARTRIDGE
-15 211-0
734-00
4
SCREW,MACHINE; 6-32 X 0.250,FLH100,STL,CDPL,T-10 TORX DR
5–12 AWG7000B and AWG7000C Series Service Manual
