Tektronix AWG7000B Series

Replaceable Parts
Table 5-18: Rep
laceable parts list – CLK12G module
Fig. & index
number
Tektronix
part number
Serial n o.
effective
Serial no.
discont’d Qty N ame & descrip
tion
5-18-
CLK12G MODULE
-1 174-5328-00 1
CABLE ASSY ELEC: RF,COAX,11.8IN L,50 OHM,SMP-R RTANG TO
SMP-R RTANG,FLEX COAX CABLE,VSWR 1.35 IL 1.3DB AT 12GHZ
-2 011-0184-00 1
TERMINATION: COAX,50 OHM,+20DBM,SMP,FEMALE,DC-18GHZ,
VSWR 1.2 AT 15GHZ 1.25 AT 18GHZ,GOLD W NI
UNDERPLATE
D,P918-1CC, TENSOLITE
(AWG7000B SERIES ONLY)
-3 211–0372–00 2
SCREW, MACH
INE; 4-40 X 0.312, PNH, STEEL, ZINC FINISH, TORX
T10
-4 211-1235-00 10
SCREW,MAC
HINE; W/HEAVY PATCH THREADLOCKING MATERIAL;
4-40 X 1.0,PNH,STL CD PLT,T10
-5
348–1931–00 1
GASKET;S
HEET FOR SMP CONNECTOR
-6 386–7508–00 1
PLATE; HOLDDOWN GASKET SHEET SMP
-7
211–0324
–00
2
SCR,ASSEM WSHR; 4-40 X 0.188,PNH,SST,PASS,T-10 TORX
DR,MACHINE
-8 211-123
7-00
1
SCREW,MACHINE; W/HEAVY PATCH THREADLOCKING MATERIAL;
4-40 X 0.75,PNH, STL CD PLT,T10
-9 352-048
2-00
2
HOLDER,CABLE TIE; 0.75 SQ,STICKY BACK,PLASTIC,SAFETY
CONTROLLED
-10 343-05
49-00
2
HOLDER,CABLE TIE; 0.75 SQ,STICKY BACK,PLASTIC,SAFETY
CONTROLLED
-11 337-4
441-00
1
SHIELD,ELEC;CASE TOP CLK12G
-12 342-1174-00 1
INSUL
ATOR; THERMAL CONDUCTIVE SHEET,0.04 G974,0.83 X
0.5,CHOMERICS
-13 342-1155-00 1
INSUL
ATOR; THERMAL CONDUCTIVE SHEET,0.04 G974,0.787 X
0.787, CHOMERICS
-14 211-0250-00 2
SCRE
W,MACHINE; 2-56 X 0.937,FLH,STL CD PL,POZ
-15 119-7434-00 1
OSCILLATOR,YIG: 4.7GHZ TO
12.
8GHZ,+12V170MA,-5V30MA,HEATER+12V70MA
MAX300MA,20MHZ/MA,+9DBM,FS2820,TELEDYNE
-16 174-5289-00 1
CAB
LE ASSY ELEC: RF,COAX,1.7IN L,50 OHM,SMP-R RTANG,SMA-P
RTANG, FLEX COAX CABLE
-17 679-6422-00 1
CI
RCUIT BD ASSY,OUTSOURCED;389-4047-XX WIRED,CLK12G
-18 210-0001-00 2
WASHER,LOCK; #2 INTL,0.013 THK,STL CD PL
-1
9
21
0-0405-00
2
NUT,PLAIN,HEX; 2-56 X 0.188,BRS CD PL
-20 342-1156-01 1
I
NSULATOR; THERMAL CONDUCTIVE SHEET,0.04 G974,2.85 X 2.10,
CHOMERICS
-21 211-0691-00 4
S
CR,ASSEM WSHR; 6-32 X 0.625,PNH,STL,CDPL,T-15 TORX
DR,MACHINE
-22 337-4442-00 1
SHIELD,ELEC;CASE BOTTOM CLK12G
-23 214–5156–00 2
PIN; LOCATING CLK12G RF SHIELD CASE UNIT
-24 407-5319-00 1
BRACKET;SHIELD CASE FOR CLK12G
AWG7000B and AWG7000C Series Service Manual 5–33
