Tektronix AWG7000B Series

Replaceable Parts
Table 5-17: Rep
laceable Parts List – AWG12G/CLK12G/OUT10G modules
Fig. &
index
number
Tektronix
part
number Model
Serial no.
effective
Serial no.
discont’d Qty Name & description
5-17-
AWG12G/CLK12G/OUT10G MODULES
-1 211-1050-00 11
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
210-0586-00
AWG7xx1B
8
NUT,PL,ASSY WA; 4-40 X 0.25,STL CD PL
-2
210-0586-00
AWG7xx2C
AWG7xx2B
16
NUT,PL,ASSY WA; 4-40 X 0.25,STL CD PL
214-5120-00
AWG7xx1B
2
HEAT SINK,SEMIC; IC,FLAT PKG,BLOCK,OUT10G, ALPHA
T40-6B MACHINED, 40 X 40 X 6MM,USED W/407520600
& 348188300
-3
214-5120-00
AWG7xx2C
AWG7xx2B
4
HEAT SINK,SEMIC; IC,FLAT PKG,BLOCK,OUT10G,ALPHA
T40-6B MACHINED, 40 X 40 X 6MM,USED W/407520600
& 348188300
407-5206-00
AWG7xx1B
1
BRACKET HEATSK; OUT10G,0.05,AL
407-5206-00
AWG7xx2B
2
BRACKET HEATSK; OUT10G,0.05,AL
-4
407-5510-00
AWG7xx2C
2
BRACKET, HEATSINK, OUT10G
342-1157-00
AWG7xx1B
1
INSULATOR; THERMAL CONDUCTIVE SHEET,0.070 G580,
1.850 X 3.250
-5
342-1157-00
AWG7xx2C
AWG7xx2B
2
INSULATOR; THERMAL CONDUCTIVE SHEET,0.070 G580,
1.850 X 3.250
211-1050-00
AWG7xx1B
9
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
-6
211-1050-00
AWG7xx2C
AWG7xx2B
18
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
-7
211-1050-00 12
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
348-1887-00
AWG7xx1B
1
GASKET,ELEC;CONDUCTIVE URETHANE FORM
0.158X0.236X0.400, W/ADHESIVE,LAIRD #4704
-8
348-1887-00
AWG7xx2C
AWG7xx2B
2
GASKET,ELEC;CONDUCTIVE URETHANE FORM
0.158X0.236X0.400, W/ADHESIVE,LAIRD #4704
348-1886-00
AWG7xx1B
1
GASKET,ELEC;CONDUCTIVE URETHANE FORM
0.158X0.236X1.000, W/ADHESIVE,LAIRD #4704
-9
348-1886-00
AWG7xx2C
AWG7xx2B
2
GASKET,ELEC;CONDUCTIVE URETHANE FORM
0.158X0.236X1.000, W/ADHESIVE,LAIRD #4704
-10 348-1888-00 1
ABSORBER,RF: 3.050X0.800X0.079,W/ADHESIVE,TDK
IRB02A2
348-1885-00
AWG7xx1
2
GASKET,ELEC;CONDUCTIVE URETHANE FORM
0.080X1.345X3.050, W/ADHESIVE, LAIRD #4315
-11
348-1885-00
AWG7xx2C
AWG7xx2B
4
GASKET,ELEC;CONDUCTIVE URETHANE FORM
0.080X1.345X3.050, W/ADHESIVE, LAIRD #4315
337-4397-00
AWG7xx1B
1
BRACKET; SHIELD,COVER,OUT10G BD
-12
337-4397-00
AWG7xx2C
AWG7xx2B
2
BRACKET; SHIELD,COVER,OUT10G BD
-13 211-1050-00 10
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
-14 211-0691-00 4
SCR,ASSEM WSHR; 6-32 X 0.625,PNH,STL,CDPL,T-15
TORX DR, M ACHINE
5–30 AWG7000B and AWG7000C Series Service Manual
