Tektronix AWG7000B Series

Replaceable Parts
Table 5-20: Rep
laceable parts list – SMA bracket
Fig. &
index
number
Tektronix
part
number Model
Serial no.
effective
Serial no.
discont’d Qty Name & description
5-20-
SMA BRACKET
-1 407-5144-00 1
BRACKET, SMA: FRONT I/O
-2 211-0734-00
5
SCREW,MACHINE; 6-32 X 0.250,FLH100,STL,CDPL,T-10
TORX DR
-3 407-5222-00 1
BRACKET, SMA: FRONT I/O BNC AREA
-4 131-8054-00 2
CONN,RF,JACK; BNC,PNL,50 OHM,FEMALE,STR,
PELTOLA/PNL MNT,SILVER ALLOY, 0.576 MLG X 0.366
TERMN,0.375-32 THD,D-FLAT
-5
174-5244-00 2
CABLE ASSY ELEC: RF,COAX,22.8IN L,50 OHM,
PELTOLA,PELTOLA,FLEX COAX CABLE
174-5344-00
AWG7xx1B
1
CABLE ASSY ELEC: RF,COAX,9.5IN L,50 OHM,SMA-R STR
PANEL,SMP-R RTA, W/LABEL,MATCHED DELAY FLEX
COAX CABLE
-6
174-5344-00
AWG7xx2C
AWG7xx2B
2
CABLE ASSY ELEC: RF,COAX,9.5IN L,50 OHM,SMA-R STR
PANEL,SMP-R RTA, W/LABEL,MATCHED DELAY FLEX
COAX CABLE
174-5343-00
AWG7xx1B
2
CABLE ASSY ELEC: RF,COAX,7IN L,50 OHM,SMP-R RTA,
SMA-R STR, PANEL MOUNT, W/LABEL,MATCHED DELAY
FLEX COAX CABLE
-7
174-5343-00
AWG7xx2C
AWG7xx2B
4
CABLE ASSY ELEC: RF,COAX,7IN L,50 OHM,SMP-R RTA,
SMA-R STR, PANEL MOUNT, W/LABEL,MATCHED DELAY
FLEX COAX CABLE
174-5337-00
AWG7121B
Option 02
1
CABLE ASSY ELEC: RF,COAX,13.8IN L,50 OHM,SMA-P
STR, SMA-R STR, PANEL MOUNT,W/LABEL,MATCHED
DELAYFLEXCOAXCABLE
-8
174-5337-00
AWG7122C
Option 06
AWG7122B
Option 06
3
CABLE ASSY ELEC: RF,COAX,13.8IN L,50 OHM,SMA-P
STR, SMA-R STR, PANEL MOUNT,W/LABEL,MATCHED
DELAYFLEXCOAXCABLE
AWG7000B and AWG7000C Series Service Manual 5–37
