Replaceable Parts

Table 5-4: Repl

aceable parts list – AWG7000B Series chassis a ssembly

Fig. & index

number

Tektronix

part number

Serial n o.

effective

Serial no.

discont’d Qty Name & descrip

tion

5-4-

CHASSIS ASSEMBLY

-1 131-6417-00 6

CONTACT,ELEC; GROUNDING,0.600 L X 0.250 W X 0.220 D,

ELECTROLESS NICKEL PLATE

-2 348-0966-00 1

GROMMET,PLASTIC;BLACK,ROUND,0.625 ID

-3 441-2536-00 1

CHASSIS, MAI

N; ASSEMBLY

Figure 5-4: AWG7000B Series chassis assembly

AWG7000B and AWG7000C Series Service Manual 5–7
