Removal and Installation Procedures
Installation.
To install, reverse this procedure.
CAUTION. The hard disk drive is extremely susceptible to static-discharge
damage, shock, dust and so on. When you store a removable hard disk assembly,
put it into an anti-static plastic bag to protect it.
Fan Tray Unit
You need a screwdriver with a T-15 Torx tip and a #2 Phillips screwdriver (items
1, 2, and 6).
Removal. To remove the fan tray unit, follow these steps: (See Figure 4-6.)
1. Remove the handle unit, snaps, cosmetic covers, front-trim unit, and EMI
covers.
2. Disconnect the fan cables from J300, J302, and J304 o n the Power board.
3. Removethefourscrewssecuringthefantrayunittothechassis.
4. Lift the fan tray unit away from the chassis.
5. Use a #2 Phillips screwdriver to remove the 12 screws securing the fans to
the fan bracket.
Install. To install, reverse this procedure.
AWG7000B and AWG7000C Series Service Manual 4–15
