Tektronix DPO7000 Series Technical Reference

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performanc e test Minimum Incoming Outgo ing Maximum
Ch2 100 mV Vert scale setting,
+5 Div position setting, -2.0 V offset
- 2.836 V
__________ __________
-2.764V
Ch2 200 mV Vert scale setting,
-5 Div position setting, +1.25 V offset
+ 2.697 V
__________ __________
+2.803V
Ch2 200 mV Vert scale setting,
+5 Div position setting, -1.25 V offset
- 2.803 V
__________ __________
-2.697V
Ch2 500 mV Vert scale setting,
-5 Div position setting, 0V offset
+ 3.394 V
__________ __________
+3.606V
Ch2 500 mV Vert scale setting,
+5 Div position setting, -0 V offset
- 3.606 V
__________ __________
-3.394V
Ch3 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
+ 524.75 mV
__________ __________
+535.25mV
Ch3 10 mV Vert scale setting,
+5 Div position setting, -0.45 V offset
- 535.25 mV
__________ __________
- 524.75 mV
Ch3 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
+ 552.75 mV
__________ __________
+567.25mV
Ch3 20 mV Vert scale setting,
+5 Div position setting, -0.4 V offset
- 567.25 mV
__________ __________
- 552.75 mV
Ch3 50 mV Vert scale setting,
-5 Div position setting, +0.25 V offset
+ 636.75 mV
__________ __________
+663.25mV
Ch3 50 mV Vert scale setting,
+5 Div position setting, -0.25 V offset
- 663.25 mV
__________ __________
- 636.75 mV
Ch3 100 mV Vert scale setting,
-5 Div position setting, +2.0 V offset
+ 2.764 V
__________ __________
+2.836V
Ch3 100 mV Vert scale setting,
+5 Div position setting, -2.0 V offset
- 2.836 V
__________ __________
-2.764V
Ch3 200 mV Vert scale setting,
-5 Div position setting, +1.25 V offset
+ 2.697 V
__________ __________
+2.803V
Ch3 200 mV Vert scale setting,
+5 Div position setting, -1.25 V offset
- 2.803 V
__________ __________
-2.697V
Ch3 500 mV Vert scale setting,
-5 Div position setting, 0V offset
+ 3.394 V
__________ __________
+3.606V
Ch3 500 mV Vert scale setting,
+5 Div position setting, -0 V offset
- 3.606 V
__________ __________
-3.394V
Ch4 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
+ 524.75 mV
__________ __________
+535.25mV
Ch4 10 mV Vert scale setting,
+5 Div position setting, -0.45 V offset
- 535.25 mV
__________ __________
- 524.75 mV
Ch4 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
+ 552.75 mV
__________ __________
+567.25mV
Ch4 20 mV Vert scale setting,
+5 Div position setting, -0.4 V offset
- 567.25 mV
__________ __________
- 552.75 mV
3–24 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
