Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performance test Minimum Incoming Outgoing Maximum
Ch4 50 mV Vert scale setting,
-5 Div position setting, +0.25 V offset
+ 636.75 mV
__________ __________
+ 663.25 mV
Ch4 50 mV Vert scale setting,
+5 Div position setting, -0.25 V offset
- 663.25 mV
__________ __________
- 636.75 mV
Ch4 100 mV Vert scale s etting,
-5 Div position setting, +2.0 V offset
+ 2.764 V
__________ __________
+ 2.836 V
Ch4 100 mV Vert scale s etting,
+5 Div position setting, -2.0 V offset
- 2.836 V
__________ __________
- 2.764 V
Ch4 200 mV Vert scale s etting,
-5 Div position setting, +1.25 V offset
+ 2.697 V
__________ __________
+ 2.803 V
Ch4 200 mV Vert scale s etting,
+5 Div position setting, -1.25 V offset
- 2.803 V
__________ __________
- 2.697 V
Ch4 500 mV Vert scale s etting,
-5 Div position setting, 0V offset
+ 3.394 V
__________ __________
+ 3.606 V
Ch4 500 mV Vert scale s etting,
+5 Div position setting, -0 V offset
- 3.606 V
__________ __________
- 3.394 V
DC voltage measurement accuracy (averaged), < 4 GHz models
Ch1 1 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 504.25 mV
__________ __________
+ 509.76 mV
Ch1 1 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 509.76 mV
__________ __________
- 504.25 mV
Ch1 2 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 512.98 mV
__________ __________
+ 519.03 mV
Ch1 2 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 519.03 mV
__________ __________
- 512.98 mV
Ch1 5 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 536.26 mV
__________ __________
+ 543.74 mV
Ch1 5 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 543.74 mV
__________ __________
- 536.26 mV
Ch1 10 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 574.20 mV
__________ __________
+ 585.80 mV
Ch1 10 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 585.80 mV
__________ __________
- 574.20 mV
Ch1 20 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 651.65 mV
__________ __________
+ 668.35 mV
Ch1 20 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 668.35 mV
__________ __________
- 651.65 mV
Ch1 50 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 884.00 mV
__________ __________
+ 916.00 mV
Ch1 50 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 916.00 V
__________ __________
- 884.00 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 3–25
