Tektronix DPO7000 Series Technical Reference

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performance test Minimum Incoming Outgoing Maximum
Ch2 50 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 916.00 V
__________ __________
- 884.00 mV
Ch2 90 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 1.194 V
__________ __________
+ 1.246 V
Ch2 90 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 1.246 V
__________ __________
- 1.194 V
Ch2 100 mV Vert scale s etting,
0 Div position setting, +4.5 V offset
+ 4.746 V
__________ __________
+ 4.854 V
Ch2 100 mV Vert scale s etting,
0 Div position setting, -4.5 V offset
- 4.854 V
__________ __________
- 4.746 V
Ch2 200 mV Vert scale s etting,
-2 Div position setting, +4.6 V offset
+ 4.725 V
__________ __________
+ 4.875 V
Ch2 200 mV Vert scale s etting,
+2 Div position setting, -4.6 V offset
- 4.875 V
__________ __________
- 4.725 V
Ch2 500 mV Vert scale s etting,
-2 Div position setting, +5.0 V offset
+ 4.345 V
__________ __________
+ 4.655 V
Ch2 500 mV Vert scale s etting,
+2 Div position setting, -5.0 V offset
- 4.655 V
__________ __________
- 4.345 V
Ch2 1.0 V Vert scale setting,
0 Div position setting, +2.0 V offset
+ 4.745 V
__________ __________
+ 5.255 V
Ch2 1.0 V Vert scale setting,
0 Div position setting, -2.0 V offset
- 5.255 V
__________ __________
- 4.745 V
Ch3 1 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 504.25 mV
__________ __________
+ 509.76 mV
Ch3 1 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 509.76 mV
__________ __________
- 504.25 mV
Ch3 2 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 512.98 mV
__________ __________
+ 519.03 mV
Ch3 2 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 519.03 mV
__________ __________
- 512.98 mV
Ch3 5 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 536.26 mV
__________ __________
+ 543.74 mV
Ch3 5 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 543.74 mV
__________ __________
- 536.26 mV
Ch3 10 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 574.20 mV
__________ __________
+ 585.80 mV
Ch3 10 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 585.80 mV
__________ __________
- 574.20 mV
Ch3 20 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 651.65 mV
__________ __________
+ 668.35 mV
Ch3 20 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 668.35 mV
__________ __________
- 651.65 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 3–27
