Tektronix DPO7000 Series Technical Reference

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performanc e test Minimum Incoming Outgo ing Maximum
Ch3 50 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 884.00 mV
__________ __________
+916.00mV
Ch3 50 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 916.00 V
__________ __________
- 884.00 mV
Ch3 90 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 1.194 V
__________ __________
+1.246V
Ch3 90 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 1.246 V
__________ __________
-1.194V
Ch3 100 mV Vert scale setting,
0 Div position setting, +4.5 V offset
+ 4.746 V
__________ __________
+4.854V
Ch3 100 mV Vert scale setting,
0 Div position setting, -4.5 V offset
- 4.854 V
__________ __________
-4.746V
Ch3 200 mV Vert scale setting,
-2 Div position setting, +4.6 V offset
+ 4.725 V
__________ __________
+4.875V
Ch3 200 mV Vert scale setting,
+2 Div position setting, -4.6 V offset
- 4.875 V
__________ __________
-4.725V
Ch3 500 mV Vert scale setting,
-2 Div position setting, +5.0 V offset
+ 4.345 V
__________ __________
+4.655V
Ch3 500 mV Vert scale setting,
+2 Div position setting, -5.0 V offset
- 4.655 V
__________ __________
-4.345V
Ch3 1.0 V Vert scale setting,
0 Div position setting, +2.0 V offset
+ 4.745 V
__________ __________
+5.255V
Ch3 1.0 V Vert scale setting,
0 Div position setting, -2.0 V offset
- 5.255 V
__________ __________
-4.745V
Ch4 1 m V Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 504.25 mV
__________ __________
+509.76mV
Ch4 1 m V Vert scale setting,
+5 Div position setting, -0.5 V offset
- 509.76 mV
__________ __________
- 504.25 mV
Ch4 2 m V Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 512.98 mV
__________ __________
+519.03mV
Ch4 2 m V Vert scale setting,
+5 Div position setting, -0.5 V offset
- 519.03 mV
__________ __________
- 512.98 mV
Ch4 5 m V Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 536.26 mV
__________ __________
+543.74mV
Ch4 5 m V Vert scale setting,
+5 Div position setting, -0.5 V offset
- 543.74 mV
__________ __________
- 536.26 mV
Ch4 10 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 574.20 mV
__________ __________
+585.80mV
Ch4 10 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 585.80 mV
__________ __________
- 574.20 mV
Ch4 20 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 651.65 mV
__________ __________
+668.35mV
3–28 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
