Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performance test Minimum Incoming Outgoing Maximum
Ch4 20 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 668.35 mV
__________ __________
- 651.65 mV
Ch4 50 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 884.00 mV
__________ __________
+ 916.00 mV
Ch4 50 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 916.00 V
__________ __________
- 884.00 mV
Ch4 90 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 1.194 V
__________ __________
+ 1.246 V
Ch4 90 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 1.246 V
__________ __________
- 1.194 V
Ch4 100 mV Vert scale s etting,
0 Div position setting, +4.5 V offset
+ 4.746 V
__________ __________
+ 4.854 V
Ch4 100 mV Vert scale s etting,
0 Div position setting, -4.5 V offset
- 4.854 V
__________ __________
- 4.746 V
Ch4 200 mV Vert scale s etting,
-2 Div position setting, +4.6 V offset
+ 4.725 V
__________ __________
+ 4.875 V
Ch4 200 mV Vert scale s etting,
+2 Div position setting, -4.6 V offset
- 4.875 V
__________ __________
- 4.725 V
Ch4 500 mV Vert scale s etting,
-2 Div position setting, +5.0 V offset
+ 4.345 V
__________ __________
+ 4.655 V
Ch4 500 mV Vert scale s etting,
+2 Div position setting, -5.0 V offset
- 4.655 V
__________ __________
- 4.345 V
Ch4 1.0 V Vert scale setting,
0 Div position setting, +2.0 V offset
+ 4.745 V
__________ __________
+ 5.255 V
Ch4 1.0 V Vert scale setting,
0 Div position setting, -2.0 V offset
- 5.255 V
__________ __________
- 4.745 V
DC gain accuracy (averaged), ≥ 4GHzmodels
Ch1 10 mV Vert scale setting,
0 D iv position setting, 0 V offset
-5 Div position setting, +0.45 V offset
+5 Div position setting, -0.45 V offset
+ 74.48 mV
+ 74.48 mV
+ 74.48 mV
__________
__________
__________
__________
__________
__________
+ 77.52 mV
+ 77.52 mV
+ 77.52 mV
Ch1 20 mV Vert scale setting,
0 D iv position setting, 0 V offset
-5 Div position setting, +0.4 V offset
+5 Div position setting, -0.4 V offset
+ 148.96 mV
+ 148.96 mV
+ 148.96 mV
__________
__________
__________
__________
__________
__________
+ 155.04 mV
+ 155.04 mV
+ 155.04 mV
Ch1 50 mV Vert scale setting,
0 D iv position setting, 0 V offset
-5 Div position setting, +0.25 V offset
+5 Div position setting, -0.25 V offset
+ 372.40 mV
+ 372.40 mV
+ 372.40 mV
__________
__________
__________
__________
__________
__________
+ 387.60 mV
+ 387.60 mV
+ 387.60 mV
Ch1 100 mV Vert scale s etting,
0 D iv position setting, 0 V offset
-5 Div position setting, +2.0 V offset
+5 Div position setting, -2.0 V offset
+ 744.80 mV
+ 744.80 mV
+ 744.80 mV
__________
__________
__________
__________
__________
__________
+ 775.20 mV
+ 775.20 mV
+ 775.20 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 3–29
