Specifications (MSO/DPO5000 Series)
Table 2-1: Analog channel input and vertical specification (cont.)
Characteristic Description
Measurement type
DC Accuracy (in volts)
Any sample
±[DC gain accuracy × | reading - (offset - position) | + offset
accuracy +0.15 div + 0.6 mV]
Refer to DC Gain Accuracy for temperature derating information.
Delta volts between any two samples
acquired with the same oscilloscope
setup and ambient conditions
±[DC gain accuracy × | reading | + 0.15 div + 1.2 mV]
Refer to DC Gain Accuracy for temperature derating information.
Sample
acquisition
mode,
typical
Offset, position, and the constant offset term must be converted to volts by multiplying by the appropriate
volts/div term.
Analog
bandwidth
selections
20 MHz, 250 MHz, and Full
Full bandwidth, with amplitude tolerance of -3 dB and operating temperatures of ≤30 °C (86 °F).
Reduce the bandwidth by 1% for each °C above 30 °C.
Instrument
SCALE range
Bandwidth
10 mV/div — 1 V/div DC to 2.00 GHz
5 mV/div — 9.98 mV/div DC to 1.50 GHz
2 mV/div — 4.98 mV/div DC to 350 MHz
MSO5204,
DPO5204
1 mV/div — 1.99 mV/div DC to 175 MHz
5 mV/div — 1 V/div DC to 1.00 GHz
2 mV/div — 4.98 mV/div DC to 350 MHz
MSO5104,
DPO5104
1 mV/div — 1.99 mV/div DC to 175 MHz
5 mV/div — 1 V/div DC to 500 MHz
2 mV/div — 4.98 mV/div DC to 350 MHz
MSO5054,
DPO5054
1 mV/div — 1.99 mV/div DC to 175 MHz
2 mV/div — 1 V/div DC to 350 MHz
Analog
bandwi
dth, 50 Ω,
DC coupled
MSO5034,
DPO5034
1 mV/div — 1.99 mV/div DC to 175 MHz
