Tektronix DPO7000 Series Technical Reference

Specifications (MSO/DPO5000 Series)
Table 2-1: Analog c hannel input and vertical specification (cont.)
Characteristic Description
Offset rangeVolts/div setting
1MΩ input 50 Ω input
1 mV/div to 50 mV/div
±1 V ±1 V
50.5 m V/div to 99.5 mV/div
±0.5 V ±0.5 V
100 mV/div to 500 mV/div
±10 V ±10 V
505 mV/div to 995 mV/div
±5 V ±5 V
1V/divto5V/div
±100 V ±5 V
5.05 V/div to 10 V/div
±50 V Not applicable
Offset ranges,
minimum
For 50 Ω path, 1 V/div is the maximum vertical setting.
The input signal cannot exceed Max Input Voltage for the 50 Ω input path. Refer to the Max Input Voltage
specification for more information.
Position range ±5 divisions
Offset
accuracy
±[0.005 × | offset - position | + DC Balance]
Both the position and constant offset term must be converted to volts by multiplying by the appropriate volts/div
term.
Number of
Waveforms
for Average
Acquisition Mode
2 to 10,000 waveforms
Default of 16 waveforms
Average of ≥ 16 waveforms ±[DC Gain Accuracy × | reading – (offset - position) | + offset
accuracy + 0.1 division ]
Refer to DC Gain Accuracy for temperature derating information.
Delta Volts between any two averages
of ≥16 waveforms acquired with the
same oscilloscope setup and ambient
conditions
±[DC gain accuracy × | reading | + 0.05 div]
Refer to DC Gain Accuracy for temperature derating information.
DC voltage
measurement
accuracy
Average
acquisition
mode
Note: Offset, position, and the constant offset term must be converted to volts by multiplying by the appropriate
volts/div term.
The basic accuracy specification applies directly to any sample and to the following measurements: H igh, Low,
Max, Min, Mean, Cycle Mean, RMS, and Cycle RMS. The delta volt accuracy specification applies to subtractive
calculations involving two of these measurements.
The delta volts (difference voltage) accuracy specification applies directly to the following m easurements:
Positive Overshoot, Negative Overshoot, Peak-to-Peak, and Amplitude.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 2–3
