Appendix G: Application Module-enabled Commands
Application Mo
dule
Commands
DPO4EMBD,
MDO3EMBD
Embedded Serial Triggering and Analysis Module. Enables triggering on packet-level information on I2C
and SPI buses as well as analytical tools such as digital views of the signal, bus views, packet decoding,
search tools,
and packet decode tables with time-s tamp information.
BUS:B<x>:I2
C:ADDRess:RWINClude
BUS:B<x>:I2C{:CLOCk|:SCLk}:SOUrce
BUS:B<x>:I2C{:DATa|:SDAta}:SOUrce
BUS:B<x>:S
PI:BITOrder
BUS:B<x>:SPI{:CLOCk|:SCLk}:POLarity
BUS:B<x>:SPI{:CLOCk|:SCLk}:SOUrce
BUS:B<x>:
SPI:DATa{:IN|:MISO}:POLarity
BUS:B<x>:SPI:DATa{:IN|:MISO}:SOUrce
BUS:B<x>:SPI:DATa{:OUT|:MOSI}:POLarity
BUS:B<x>
:SPI:DATa{:OUT|:MOSI}:SOUrce
BUS:B<x>:SPI:DATa:SIZe
BUS:B<x>:SPI:FRAMING
BUS:B<x>
:SPI:IDLETime
BUS:B<x>:SPI{:SELect|:SS}:POLarity
BUS:B<x>:SPI{:SELect|:SS}:SOUrce
SEARCH:
SEARCH<x>:TRIGger:A:BU S:B<x>:I2C :AD DR ess :MO De
SEARCH:SEARCH< x>:TR IGger:A:BUS :B<x>:I2C :ADDR ess :TYPe
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:I2C:ADDRess:VALue
SEARCH
:SEARCH<x>:TR IGger:A:BUS :B<x>:I2C :CO ND ition
SEARCH:SEARCH <x>:TR IGger:A:BU S :B<x>:I2C :DATa:DIRection
SEARCH:SEARCH <x>:TR IGger:A:BU S:B<x>:I2C :DATa:SIZe
SEARC
H:SEARCH<x>:TRIGger:A:BUS:B<x>:I2C:DATa:VALue
SEARCH:SEARCH< x>:TR IGger:A:BU S:B<x>:SPI:C ON D ition
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:SPI:DATa{:MISO|:IN}:VALue
SEARC
H:SEARCH<x>:TRIGger:A:BUS:B<x>:SPI:DATa{:MOSI|:OUT}:VALue
SEARCH:SEARCH< x>:TR IGger:A:BUS :B<x>:SPI:D ATa:SIZe
TRIGger:A:BUS:B<x>:I2C:ADDRess :MODe
TRIG
ger:A:BUS:B<x>:I2C:ADDRess:TYPe
TRIGger:A:BUS:B<x>:I2C:ADDRess:VALue
TRIGger:A:BUS:B<x>:I2C:COND ition
TRI
Gger:A:BUS:B<x>:I2C:DATa:DIRection
TRIGger:A:BUS:B<x>:I2C:DATa:SIZe
TRIGger:A:BUS:B<x>:I2C:DATa:VALue
TRI
Gger:A:BUS:B<x>:SPI:CONDition
TRIGger:A:BUS:B<x>:SPI:DATa{:IN|:MISO}:VALue
TRIGger:A:BUS:B<x>:SPI:DATa{:OUT|:MO SI}:VALue
TR
IGger:A:BUS:B<x>:SPI:DATa:SIZe
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual G-9
