Tektronix TDS3000B Series User Manual

Measure
3-40
TDS3000B Serie s User Manual
Bottom DescriptionSide
High-Low Setup Auto Select Automatically uses the best measure-
ment method depending on the signal
characteristics.
Histogram Use to measure pulses.
Min-Max Use to measure other wave shapes.
Reference Levels Set Levels in %
or units
Use to choose custom reference
levels in relative or absolute units.
High Reference Sets custom high reference level.
Mid Reference Sets custom mid reference level.
Mid2Ref Sets the custom mid reference level
for the Delay and Phase measurement
second waveform.
Low Reference Sets custom low reference level.
Set to Defaults Sets reference levels to default values.
Indicators Measurement 1--
Measurement 4
Selects the measurement for which to
display markers that show the portion
of the waveform used to calculate the
measurement value.
Off Turns measurement indicators off.
