TDS3000B Serie s User Manual
A-1
Appendix A: Specifications
This appendix contains specificat ions for t he T DS3000B Series
oscilloscopes. All specifications are guaranteed unless noted as
“typical.” Typical specifications a re provi ded for your convenie n ce
but are not guaranteed. Specifications t hat are marked with the
n symbol are checked in Appendix E: Performance Verification.
All specifications apply to all TDS3000B Series models unless noted
otherwise. To meet specific ations, two conditions must first be met:
H The oscilloscope must have been operating continuously for
twenty minutes within the operating temperature range specified.
H You must perform the Compensate Signal Path operation
described on page 1--4. If the operating temperature cha nges by
more than 10° C, you must perform t he Compensate Signal Path
operation again.
Specifications
Acquisition
Acquisition modes Sample (Normal), Peak detect, Envelope, and Average
Single Sequence Acquisition mode Acquisition stops after
Sample, Peak Detect One acquisition, all channels
simultaneously
Average, Envelope N acquisitions, all channels
simultaneously, N is settable
from 2 to 256 (or ∞ for Enve-
lope)
To Next Page
