Tektronix TDS3000B Series User Manual

Trigger Controls
TDS3000B Serie s User Manual
3-69
Video Trigger
Choose video triggering to trigger on the odd fields, eve n fields, or
on all the lines of an NTSC, PAL, or SECAM video signal. See the
TDS3VID Extended Vide o or TDS3SDI 601 Digital Vide o
application module m anual for more informat ion if that module is
installed.
Bottom Side Description
Type Video
Standard 525/NTSC Triggers on a NTSC signal.
625/PAL Triggers on a PAL signal.
SECAM Triggers on a SECAM signal.
Source See page 3--64 for descriptions of
these menu items.
Trigger On Odd Triggers on odd or even fields in an
i
n
t
e
r
l
a
c
e
d
s
i
g
n
a
l
Even
interl
a
ced sign
a
l.
All Fields Triggers on any field in an interlaced
or noninterlaced signal.
All Lines Triggers on all lines.
Mode & Holdoff See page 3--66 for descriptions of
these menu items.
Key Points
Displaying the Trigger Source. You do not have to display a channe l t o
use it as a trigger source.
Sync Pulses. When you choose Video, the tri gger always oc curs on
negative-going sync pulses. If your video signal has positive-going
sync pulses, invert the signal using the Vertical menu. See page 3 --81
for information about invert ing a signal.
