Appendix A: Specifications
TDS3000B Serie s User Manual
A-11
Specifications (cont.)
Environmental
Altitude Operating limit: 3000 m
Nonoperating limit: 15,000 m
Random vibration Operating: 0.31 g
RMS
from 5 Hz to 500 Hz, 10 minutes on each
axis
Nonoperating: 2.46 g
RMS
from 5 Hz to 500 Hz, 10 minutes on
each axis
Drop resistance, typical Survives a 152 mm (6 in) drop onto concrete with only cosmetic
damage
Mechanical
Size Height: 176 mm (6.9 in), 229 mm (9.0 in) including handle
Width: 375 mm (14.75 in)
Depth: 149 mm (5.9 in)
Weight Oscilloscope only: 3.2 kg (7.0 lbs)
With accessories and carry case: 4.1 kg (9.0 lbs)
When packaged for domestic shipment: 5.5 kg (12.0 lbs)
Optional TDS3BATB battery pack: 0.85 kg (1.9 lbs)
