Tektronix TDS3000B Series User Manual

Acquisition Controls
TDS3000B Serie s User Manual
3-7
Bottom DescriptionSide
WaveAlert Wfm Anomaly
Detection
On Off
Enables or disables the WaveAlert
function. See page 3--13 for an explana -
tion of WaveAlert.
Sensitivity
nn.n%
Sets the WaveAlert sensitivity. Use the
general purpose knob to set sensitivity
from 0% (least sensitive) to 100% (most
sensitive).
Beep On
Anomaly
On Off
When On, the oscilloscope beeps when
it detects a waveform anomaly on any
active channel.
Stop On
Anomaly
On Off
When On, the oscilloscope stops
waveform acquisition when there is a
waveform anomaly on any channel. The
input waveforms and anomalies remain
displayed on the screen.
Hard Copy
On Anomaly
On Off
When On, the oscilloscope sends an
image of the screen to the hard copy
device or floppy file when there is a
waveform anomaly on any channel.
Wfms to Disk
On Anomaly
On Off
When On, the oscilloscope saves the
anomalous waveform(s) data to a file on
the floppy disk drive.
Highlight
Entire Wfm
Highlights the entire anomalous wave-
form.
Highlight
Anomalies
Highlights just the anomalous data in a
waveform.
