Reference
File extension File type
*.MSK Mask geometry
file (requires TDS3TMT module)
*.PNG Hard copy file,
Portable Network Graphics format
*.C60, *.C80 Hard Copy file
, Epson C60 or C80 inkjet format
Trigger Controls
Push the Trigger Menu button, and then push the Type screen button to select
Edge, Logic, Pulse, or Video. If installed, see the user manual for the TDS3VID
Extended Video, the TDS3SDI 601 Digital Video, or the TDS3TMT Telecom
Mask Test application module for more information.
Trigger L
evel
Use the trigger Level control to adjust the trigger level. When you change the
trigger level, a horizontal line temporarily appears to show y ou the level on
screen
. After the line disappears, the trigger level is marked with a small arrow.
Trigger level marker
Trigger level readout
Set to 50%
Push the Set To 50% button to set the trigger level to the 50% amplitude level of
the trigger source waveform.
90 TDS3000C Series Oscilloscope User Manual
