Getting Started
Latching tab
To remove a communication module, follow these steps:
1. Turn the oscilloscope power off.
2. Press down on the latc hing tab and then use a small screw driver to alternately
pry out the sides of the communication module.
3. Slide out the communication module and store it in an ESD-shielded bag.
Install the blank cover.
Communication port For more information, see
GPIB
RS-232
The TDS3000, TDS3000B, and TDS3000C Series Digital
Phosphor Oscilloscopes Programmer Manual, and Hard Copy in
this u
ser manual. (See page 65.)
VGA Spec
ifications for the I/O ports in Appendix A in this user manual.
14 TDS3000C Series Oscilloscope User Manual
