Application Examples
Taking Cursor
Measurements
You can use the cursors to take quick measurements on a waveform. To measure
the ring frequency at the rising edge of the signal, follow these steps:
1. Push the Cursor button.
2. Push the Function screen button.
3. Select VBarscursors.
4. Push the VBarUnitsscreen button.
5. Select 1/seconds (Hz).
6. Place
one cursor on the first peak of the ring using the general purpose knob.
7. Push the Select button.
8. Place the other cursor on the next peak of the ring.
The cursor Δ readout shows the measured ring frequency is 227 kHz.
TDS3000C Series Oscilloscope User Manual 35
