Appendix D: Probe Basics
Index Description Part
16 Probe to connector pin adapter 015-0325-01
17
50 Ω BNC-to-probe tip termination and adapter
013-0227-00
18
Ground contact kit (two each of five lengths) with cover shell
016-1077-00
19
Grounding probe tip
013-0085-00
20 Adapter to use with the grounding probe tip, or with the probe to connector pin adapter 013-0202-04
Using Othe
rProbes
Optional probes can add capabilities to your oscilloscope that are useful in many
applications. You can use the following passive probes without any limitations.
Passive probe Recomm ended usage
P5100
High-voltage probe, 2500 V
pk
CAT II, 250 MHz, 100X
P6015A
High-voltage probe, 20 kV DC, 75 M Hz, 1000X
P6021
Current probe, 15 A, 120 Hz to 60 MHz
P6022
Current probe, 6 A, 935 Hz to 120 MHz
P6158
Low capacitance probe, 3 G Hz, 20X (50 Ω)
Supported Active Probes and Adapters
The oscilloscope supplies power to active probes. You can use the following
active probes as long as the total power required by the probes does not exceed
the capacity of the oscilloscope. To determine the total probe load, add the load
fac
tors for all probes you want to use. The oscilloscope can supply power to this
combination if the sum of the load factors equals 10 or less. All passive probes
have a load factor of zero.
Ac
tive probe
Re
commended usage
Lo
ad factor
P6205 FET probe, 750 MHz, 10X 0
P6243
SMT probe, 1 GHz, 10X
0
P5205
High-voltage differential probe, 1300 V,
100 MHz, 50X or 500X
6
P5210
High-voltage differential probe, 5600 V, 50 MHz,
100X or 1000X
6
ADA400A
Differential preamplifier, 10 μV sensitivity, DC
to 10 kHz
5
AMT75
Telecom 75 Ω adapter
0
144 TDS3000C Series Oscilloscope User Manual
