Reference
Switching Betw
een XY and YT. You can switch between XY and YT display mode
to see the location of the cursors in the YT waveform. The waveform record
icon at the top of the graticule also shows the relative cursor positions in the
waveform record.
W aveform Sources. You can use XY cursors on active acquisitions, single
sequence ac
quisitions, and reference waveforms. You need to store both X Y
source waveforms in order to recreate an XY waveform. The X axis waveform
must be stored in Ref1.
Display
Push the Display button to show the display menu.
Bottom Side Descrip
tion
Dots Onl
y
Set to on
to see dots only. Set to off to
see dots and vectors.
Persis
tTime
Sets persist time.
Set to Auto Sets the Waveform Intensity knob to
control the persistence time.
Wavefor
m
Display
Clear
Pers
istence
Clears any displayed persistence.
High
Use f
or bright ambient conditions.
Medium
Use
for dim ambient conditions.
Backlight
Inte
nsity
Low Use to extend battery-operation time.
Graticule Full, Grid,
Cr
oss Hair,
Frame
Sets the graticule type.
Off (YT) Turns off an XY display.
T
riggered XY
T
urns on triggered XY display.
G
ated XYZ
Turns on gated XY display. Displays XY
s
ignals when Z-channel signal is above
a set level. Only available on 4-channel
instruments.
Ch1 (X) Versus Sets Ch2, Ch3, or Ch4 as the Y channel
versus Ch1 as X .
Sets Ref2, Ref3, or Ref4 as the Y
channel versus Ref1 as X.
XY
Display
Ref1 (X)
Versus
Gated By
Sets Ch2, Ch3, or Ch4 as the Z-channel
gate source, and sets the gating
channel threshold level.
Normal
Selects the color display.
Color
Palette
Monochrome
Sets a ll waveforms to high-contrast
black and white.
TDS3000C Series Oscilloscope User Manual 63
