Appendix D: Probe Basics
This appendix contains basic information about the P3010 or P6139A probes
provided with your oscilloscope. It also contains information about other probes
you can use with your oscilloscope and their limitations.
Probe Descriptions
The P3010 and P6139A are high-impedance passive probes with the following
general characteristics.
Characteristic P3010 P6139A
Cable length
2m 1.3m
Compatibility
100 MHz oscilloscope
models
300 MHz and 500 MHz
oscilloscope models
Bandwidth 100 MHz 500 MHz
Attenuation 10X 10X
Nominal input impedance
10 MΩ in parallel w ith 13 pF 10 MΩ in parallel with 8 pF
Maximum working voltage
300 V, CAT II, derated at
20 dB/decade to 50 V above
2.5 MHz
300 V, CAT II, derated at
20 dB/decade to 50 V above
2.5 MHz
Altitude 3,000 m 2,000 m
Temperature Range
Operating -15 °C to +55 °C
(+5°Fto+131°F)
-15°Cto+65°C
(+5 °F to +149 °F)
Non Operating -62 °C to +85 °C
(-80 °F to +185 °F)
-62°Cto+85°C
(-80 °F to +185 °F)
Pollution Degree 2, Indoor use only 2, Indoor use only
Probe Compensation
You should compensate a probe to an oscilloscope input whenever you attach a
probe for the first time to any input channel. (See page 3, Probe Compensation.)
When compensating the P3010, only adjust the trimmer marked L.
TDS3000C Series Oscilloscope User Manual 139
