Application Examples
To display
the signals connected to channels 1 and 2, follow these steps:
1. Push the channel 1 and 2 buttons to activate both channels.
2. Push the Autoset button.
To select measurements for the two channels, follow t hese steps:
1. Push the Meas button to see the Select Measurement menu.
2. Push the channel 1 button and then push the Select Measurement for Ch1
screen button.
3. Select the Amplitude measurement.
4. Push t
he channel 2 button and then push the Select Measurement for Ch2
screen button.
5. Sele
ct the Amplitude measurement.
TDS3000C Series Oscilloscope User Manual 29
