Specifications
The specifications shown apply to the THDP/TMDP series probes installed on Tektronix MSO/DSO4000 oscilloscopes. When a probe is
used with another oscilloscope, the oscilloscope must have an input impedance of 1 MΩ and a bandwidth equal to or greater than the
probe. The probe must have a warm-up period of at least 20 minutes and be in an environment that does not exceed the limits described.
See Table 5 on page 39. Specifications for the THDP/TMDP series probes fall into three categories: warranted, typical and nominal
characteristics.
Warranted specifications
Warranted characteristics describe guaranteed performance within tolerance limits or certain type-tested requirements.
Table 4: Warranted electrical specifications
Characteristics THDP0100 THDP0200 TMDP0200
Rise time (small signal, 10–90%,
+20 °C to +30 °C). Output may be
slew rate limited for large amplitude
signals.
600 V: ≤3.6 ns(typical:
≤3.5 ns)
150 V: ≤2.4 ns(typical: ≤2.2 ns) 75 V: ≤2.4 ns(typical: ≤2.2 ns)
6000 V: ≤3.6 ns(typical:
≤3.5 ns)
1500 V: ≤2.0 ns(typical:
≤1.8 ns)
750 V: ≤2.0 ns(typical: ≤1.8 ns)
(slew rate ≥2500 V/ns
(6000 V))
(slew rate ≥650 V/ns (1500 V)) (slew rate ≥275 V/ns (750 V))
DC gain accuracy ±2% ±2% ±2%
Table 5: Warranted environmental specifications
Characteristics THDP0100 THDP0200 TMDP0200
Operating Temperature 0 °C to 40 °C (32 °F to +104 °F)
Nonoperating Temperature –30° C to +70° C (–22 °F to +158 °F)
Operating Humidity 5 to 85% RH (Relative Humidity) 0 °C to +40 °C (32 °F to +104 °F)
Nonoperating Humidity 5% to 85% RH at up to +40° C (+104 °F). 5% to 45% RH above +40° C up to +70° C (+104 to
+158 °F)
Operating Altitude 3,000 m (9,842 ft)
Nonoperating Altitude 15,240 m (50,000 ft)
Specifications
High Voltage Differential Probes THDP0100/0200 and TMDP0200 User Manual 39
