Tektronix THDP0100 User Manual

Test record
Photocopy this test record for recording the results of the performance verification procedures.
Table 12: THDP and TMDP Series probes test record
Probe Model:
Probe Serial Number:
T
emperature:
Certificate Number:
RH%:
Technician:
Date of Calibration:
Probe test Range Minimum Incoming Outgoing Maximum
THDP0100 gain accuracy 600 V 735 mV 765 mV
6000 V 73.5 mV 76.5 mV
THDP0200 gain accuracy
150 V 490 mV 510 mV
1500 V 147 mV 153 mV
TMDP0200 gain accuracy
75 V 784 mV 816 mV
750 V 235.2 mV 244.8 mV
THDP0100 rise time
600 V — 3.6 ns
6000 V — 3.6 ns
THDP0200 rise time
150 V — 2.4 ns
1500 V — 2.0 ns
TMDP0200 rise time
75 V — 2.4 ns
750 V — 2.0 ns
Performance verification
50
