Performance verification
Use the following procedures to verify the warranted specifications of the probes. Before beginning these procedures, photocopy the test
record and use it to record the performance test results. See Test record on page 50. The recommended calibration interval is one year.
These procedures test the following specifications:
• Gain accuracy
• Rise time
Required equipment
The equipment required to perform the performance verification procedures are shown in the table below. The types and quantities of
connectors may vary depending on the specific equipment you use.
Table 9: Equipment required
Description Minimum requirements Example product
Oscilloscope 500 MHz Tektronix MSO/DSO4000
Generator ±100V variable amplitude, 100 Hz square wave, calibrated Fluke 9100
Pulse generator ≥50 V, 200 ns pulse width, ≤500 ps rise time, 1 kHz Avtech AVR-E2-B-W-P
Probe calibration fixture TekVPI input Tektronix part number 067-1701-xx
Digital Multimeter (DMM) 100 mV and 1 V true RMS AC ranges, <±0.3 % accuracy Tektronix DMM4040/4050
Cable Coax, BNC, 50Ω, 36 in Tektronix part number 012-0482-xx
Adapter BNC female-to-SMA male
Tektronix part number 015-1018-xx
Adapter BNC female-to-dual banana female Tektronix part number 103-0090-xx
Adapter BNC female-to-female Tektronix part number 103-0028-xx
Adapter BNC male-to-dual banana male Fluke PM9081
Termination BNC feedthrough, 50Ω Tektronix part number 011-0049-xx
Attenuator BNC, 50Ω, 2X Tektronix part number 011-0069-xx
Probe hook tips (2) Included with probe accessory kit Tektronix part number AC280–FL
Performance verification
46
