Tektronix WFM7020 Technical Reference

Specifications
The following tables list the specifications for the Tektronix WFM6120,
WFM7020, and WFM7120 Waveform Monitors. Items listed in the Performance
Requirement
column are generally quantitative and can be tested by the
Performance Verification procedure in Section 2 of this manual. Items listed in the
Reference Information column are useful operating parameters that have typical
values; information in this column is not guaranteed.
The specifications listed in the Electrical Specifications portion of these tables
apply over an ambient temperature range of +0 °C to +40 °C. The rated accuracies
are valid when the instrument is calibrated in an ambient temperature range of
+20 °C to +30 °C.
NOTE. Al
lHDspecifications apply to 3 Gb/s unless noted otherwise.
Electrical Specifications
Table 1: SDI Input Waveform Vertical Characteristics
Characteristic Performance requirement Reference inform ation
Using graticule or cursor. Measure in YPbPr
mode.
1X
± 0.5% of 700 mV full scale mode
Vertical
Measurement
Accur
acy
5X
± 0.2% of 700 mV full scale mode
Gain
X1, X2, X5, and X10
Variable Gain Range, Typical 0.25X to 1.8X, typical (variable gain multiplied
by
fixed gain to get total gain).
Luminance
Ch
annel (Y)
50
kHz to 30 MHz, ± 0.5%
50
kHz to 60 MHz for 1080P 60/59/50 dual
link formats.
Frequency
Re
sponse -
HD
Chrominance
Channels (Pb,
P
r)
50 kHz to 15 MHz, ± 0.5% 50 kHz to 30 MHz for 1080P 60/59/50 dual
link formats.
Luminance
Channel (Y)
50 kHz to 5.75 MHz, ± 0.5%
Frequency
Response -
SD
Chrominance
Channels (Pb,
Pr)
50 kHz to 2.75 MHz, ± 0.5%
YPbPr to RGB Conversion
Accuracy
0.1%, nominal
Waveform Monitors Specifications and P erformance Verification 1
