Tektronix WFM7020 Technical Reference

Specifications
Table 35: Serial Digital Video Interface (Input A, Input B) (cont.)
Characteristic Performance requirement Reference inform ation
With 1/SQRT(f) c haracteristic at ½ of serial
rate.
SD
0 to 23 dB attenuation typical
Equivalent to approximately 230 m of Belden
8281 at 270 Mb/s. Typical performance to
295 m.
Cable Loss
Accommodation
HD 0 to 20 dB attenuation typical
Equivalent to approximately 80 m of Belden
8281 at 1.485 Gb/s. Typical performance
to 110 m
For Full
Specification
800 mV ± 10%
Launch
Amplitude
Accommodation,
Typical
Up to
20 dB Cable
Loss
800 mV ± 30%
Jitter Tolerance, Typical 0.35 UI
p-p
above 2 MHz. Increases
proportional to 1/f below 2 MHz
Return Loss, Typical
>15dBto1.5GHz
Isolation Between Inputs
>45dBto1GHz
Time Base Range >± 50ppm
Tab
le 36: Serial Video Output (Serial Out/SDI PixMon)
Characteristic Performance requirement Reference inform ation
For
mat
1.485 Gb/s, 1.4835 Gb/s, or 270 Mb/s same
as selected input. With Simultaneous inputs,
co
nfigurable to be Channel 1 or Channel 2
With 1080P 60/59/50 dual link formats,
combined links are down-converted to the
re
lated 1080i 4:2:2 single link format
With other dual link formats, combined links
are down-converted to the related 4:2:2
1
0-bit single link format
C
ontent - Follows Active Input With
Brightups
S
electable as loop out A or loop out B or
Digital version of RGB/YPbPr analog pix
monitor output. Gamut and/or line select
brightups optionally displayable. For dual
link formats, Pix Mon may be con fi gured to
display picture from link A alone, link B alone,
or links A and B combined
Gamut error brightups appear one line below
error
Output Level 800 mV, ± 10% into 75 Ω load
Waveform Monitors Specifications and P erformance Verification 31
