Tektronix WFM7020 Technical Reference

Specifications
Table 4: Waveform Sweep (Horizontal) Deflection (cont.)
Characteristic Performance requirement Reference information
Timing Cursor Delta Readout
Accuracy, Typical
± 0.5% of sweep time displayed on screen
Rates
1, 2, 3, or 4 line, or field depending on mode
Line Select In 2-line sweep, the selected line is the first
displayed line.
Table 5: E
ye Pattern Display
Characteristic Performance requirement Reference information
Type
Equivalent Time Sampler
Format
s
SD and HD. (See Table 48 on page 37.)
Signal Bandwidth 100 MHz to 2.5 GHz at –3 dB point
SD 60 ps
p-p
in 1 kHz high-pass filter mode
Time B
ase
Jitter, Typical
HD
20 ps
p-p
in 1 kHz high-pass filter mode
Eye Clock Bandwidth Settings Clock bandwidth can be set to 10 Hz, 100 Hz,
1000 Hz, 10 kHz, or 100 kHz high pass filter
Eye Clock Bandwidth Accuracy Actual –3 dB frequency within 10% of nominal
HD
10
Hz
High
Pass
F
ilter
Within 0.3 UI + 10% for jitter frequencies
above five times bandwidth selection
100 Hz to
1
00 kHz
High
Pass
Filter
W
ithin 0.05 UI + 10% for jitter frequencies
above five times bandwidth selection
SD
Jitter
Attenuation
Er
ror
All High
Pass
Filter
settings
Within 0.05 UI + 10% for jitter frequencies
above five times bandwidth selection
Waveform Monitors Specifications and P erformance Verification 5

Tektronix WFM7020 Specifications

General

Brand	Tektronix
Model	WFM7020
Category	Monitor
Language	English
