Specifications
Table 18: Data e
rror detection (EDH / Status, Under STATUS Button)
Characteristic Performance requirement Reference inform ation
SD Active picture and full field. Field rate
resolution Complies with SMPTE RP165
Uses CRC check-word system. System
is known as EDH (Error Detection and
Handling) in
industry literature
Error icon asserted for 1 second after any
error
Data Integrit
y
HD
Field rate Resolution, separate reporting for
errors in Y o
r Color Difference data streams
Error icon asserted for 1 second after any
error
Table 19: ANC Data and ARIB
Characteristic Performance requirement Reference inform ation
Displays
Detects ANC data in SDI streams, displays
data from user specified DID and SDID.
Displays Audio Control Packet. Decodes
data for ARIB types B39, B37, B35, TR-B22,
and TR-B23.
Alarms
Allows Alarms to be set for : ANC
Parity ANC Checksum B39 Absence
B37 Absence B35 Absence TR-B22 Absence
TR-B23 Absence
Table 20: Audio Bar Displays
Chara
cteristic
Perfo
rmance requirement
Refer
ence inform ation
The u
ser may configure the response
dynamics (ballistics), reference levels, peak
hold, offset, and scale of the meters to
suit
the monitoring needs of the particular
installation or situation
Channel Mode Any 10 channels configured into 5 pairs
with phase correlation meters between
pai
rs; analog audio inputs havea6channel
maximum
Surround
Mode
Left, Right, Center Lfe, Left surround, Right
surround meters, and an extra channel pair.
Ph
ase correlation meters between L-R, L-C,
C-R, Ls-Rs, L-Ls, R-Rs and the extra pair
In Dolby mode, the bar configuration is
a
utomatically set by metadata
Modes
Dual Audio
D
isplay Mode
For Simultaneous inputs, Dual Audio
Displays are available. A total of 8 bars may
be allocated between the two displays. Dolby
decoding may be enabled for either display,
but not for both
Waveform Monitors Specifications and P erformance Verification 17
