Specifications
Table 6: Jitter
Display (Option EYE and PHY)
Characteristic Performance requirement Reference information
Type Displays nume
rical and graphical readouts
of peak-to-peak jitter. Jitter derived from
demodulated recovered clock as described
in SMPTE RP19
2 2003. If Opt. PHY is
installed, then Jitter Waveform can also be
displayed
High-Pass Filter Settings Can be set to 10 Hz, 1 kHz, 10 kHz, or
100 kHz.
High pass filter has type-3 response for low
frequency rejection of 60 dB/decade below
the filter s
etting. High pass filter also applies
to digital readout, jitter waveform and Eye
diagram display, but not the reference clock
output. Th
ere are two independent Jitter
demodulators which may be configured with
different loop bandwidths. One is applied to
the upper
two tiles of the display, and the
other applies to the lower two tiles
High-Pa
ss Filter Attenuation
Accuracy
Frequen
cy at which response is –3dB is
within 10% of nominal
High-Pass Frequency Response also applies
to reado
ut and jitter waveform
High-End Frequency Response,
Typica
l
–3 dB at > 5 MHz
Applie
s to digital readout, jitter waveform,
and reference clock output
Waveform Monitors Specifications and P erformance Verification 7
