Tektronix WFM7020 Technical Reference

Specifications
Table 32: External XGA Output (EXT DISPLAY) (cont.)
Characteristic Performance requirement Reference inform ation
Color Palette
6 bits per component
Connector Pin Assignments
Pin 1: R
Pin 2: G
Pin 3: B
Pin 4: N C
Pin 5: GND
Pin 6: GND
Pin 7: GND
Pin 8: GND
Pin 9: N C
Pin 10: NC
Pin 11: NC
Pin 12: NC
Pin 13: HSync
Pin 14: VSync
Pin 15: NC
Table 33: LTC Time Code Input / Ground Closures
Chara
cteristic
Perfo
rmance requirement
Refer
ence inform ation
LTC I
nput Connector
Bala
nced, unterminated via rear-panel G C
remote connector. (See Table 40.)
LT C Input Impedance Greater than 10 kΩ
LT C Signal Characteristics Longtitudinal Time Code per IEC P ublication
461
LT C Signal Amplitude Range,
Ty
pical
0.2 V
p-p
to 5.0 V
p-p
, balanced differential or
si
ngle-ended
Waveform Monitors Specifications and P erformance Verification 29
