Tektronix WFM7020 Technical Reference

Specifications
Table 8: Component Vector Mode (cont.)
Characteristic Performance requirement Reference information
Display to Graticule R egistration ± 0.5%
Fully digital system limited by samp le
resolution
Vector Display P
B
is displayed on horizontal axis and P
R
is
displayed on vertical axis
Table 9: Waveform Mode Filter Characteristics
Characteristic Performance requirement Reference information
SD,
compone
nt
only
1 ± 0.1% relative to flat gain
Low Pass
Filter Gain
HD,
component
only
1 ± 0.1% relative to flat gain
SD,
compo
nent
only
≤ 3 dB attenuation at 800 kHz
≥ 32 dB attenuation at 3 MHz
Filte
r meets IEEE STD-205
Low Pass
Filter
Freque
ncy
Response
HD,
compo
nent
only
≤ 3 dB attenuation at 4.5 MHz
≥ 25 dB
attenuation above 15 MHz, Noise
bandwidth is approximately 8 MHz Stopband
null at 18 MHz
For 10
80P 60/59/50 dual link formats:
≤3 dB attenuation at 9 MHz
≥25 dB attenuation above 30 MHz
Luma Filter Gain, composite only 1 ± 0.1% relative to flat gain at 50 kHz
Luma Filter Frequency Response,
composite only
≤ 3 dB attenuation at 800 kHz
32 dB attenuation at F
SC
Sam
e as SD serial component low pass filter
Ch
roma Filter Gain, composite
only
1±
0.1% relative to flat gain
Chroma Filter Response,
composite only
3d
B bandwidth 1MHz ± 0.2 MHz
F
SC
autoselected based on input standard,
implemented digitally, centered on F
SC
Chroma Filter Attenuation at 2x
F
SC
, composite only
≥ 25 dB
Implemented digitally. Typically 28 dB for
N
TSC, 53 dB for PAL
