Tektronix WFM7020 Technical Reference

Specifications
Table 42: Misce
llaneous
Characteristic Performance requ irement Reference information
Real-time Clock Battery Life
>10 year
Physical Spe
cifications
Table 43: Physical Characteristics
Characteri
stic
Standard
Height
51/4inche
s (133.4 millimeters)
Width
81/2inch
es (215.9 millimeters)
Dimensions
Depth
18 1/8 inc
hes (460.4 millimeters)
Net
12 pound
s (5.5 kilograms)
Weight
Shippi
ng
21 poun
ds (9.6 kilograms), approximate
Table 44: Environmental Performance
Category Standards or description
Operating 0 °C to +40 °C
Temperature
Non Operating –20 °C to +60 °C
Operating 20% to 80% relative humidity (% RH) at up to
+40 °C, non-condensing
Humidity
Non Operating 5% to 90% RH (relative humidity) at up to
+60 °C, non-condensing
Operating Up to 9,842 feet (3,000 meters)
Altitude
Non Operating Up to 40,000 feet (12,192 meters)
Cooling
Variable Fan. Forced air circulation with no air
filter.
Required Clearances
Do not block the bezel or rear panel vent holes,
or more than half the vent holes on the sides
Waveform Monitors Specifications and P erformance Verification 35
