Tektronix WFM7020 Technical Reference

Video and General Performance Verification Procedures
Video and Gene
ral Performance Verification Procedures
This perform
ance verification includes procedures that verify standard and
option-equipped instruments.
Required Equipment
Table 64: Required Test Equipment (Video and General Performance)
Test Equipm ent Requirements Example
XGA Monitor Computer monitor capable of 1024 x 768
x60Hzscanrate
NTSC Black Tektronix TG2000 with BG1 and additional
modules indicated below:
1080i 59.94 HD signals required for
WFM7120:
75% and 100% color bars
SDI Matrix Split Field Pathological
Signal
SDI Equalizer
VM5000 Matrix
HDVG1 module for TG2000 (Embedded
audio needed for audio options DG, AD,
DS, DDE)
HD signal with adjustable SDI amplitude
required for WFM7120
HDST1 module for TG2000
1080i 59.94 analog tri-level sync required
for WFM7120
AWVG1 module for TG2000
525/270 SD signals required:
75% and 100% color bars
SDI Matrix Pathological Signal
SDI Equalizer
Adjustable SDI amplitude
VM5000 Matrix
DVG1 with option S1 module for TG2000
(Embedded audio needed for audio
options DG, AD, DS, DDE)
Composite signals required for Option
CPS:
NTSC 0% flat field
NTSC 100% color bars
AVG1 module for TG2000
SDI serial digital video test generator with
embedded audio and composite signal
source
Precision calibration signals for Option
CPS and for Eye Gain test
1
Tektronix part number 067-0465-00
(AVC1) module for TG2000
2
HD Cable-clone cable simulator Simulate 10 to 150 meters of 1694A
equivalent in 10 m steps
Faraday FFE Kit
Waveform Monitors Specifications and P erformance Verification 81
