Video and General Performance Verification Procedures
Table 64: Required Test Equipment (Video and General Performance) (cont.)
Test Equipm ent Requirements Example
SD Cable-clone cable simulator Simulate 0 to 400 meters of 8281
equivalent in 25 meters steps.
Faraday S C75A800B -G
75 Ω coaxial cables
(3 required)
General purpose digital video
Male-to-male BNC connectors 1 or
2 meters long
Belden 8281
Tektronix part numbers 012-0159-00 or
012-0159-01
75 Ω Terminator for Analog Video
Male connector, precision Tektronix part number 011-0102-03
75 Ω term for SDI signal. (2)
Male, wideband Tektronix part number 011-0163-00
Video Measurement Set Measure 1080i/60 RGB Multiburst
PIXMON output
Tektronix VM5000
Sync pickoff adapter
Tektronix part number 012-1680-00
Test oscilloscope
>2 GHz bandwidth with 75 Ω input Tektronix TDS7404B with TCA75 adapter
75 Ω calibration kit M aury 8580A 75 Ω BNC
VITC Generator Horita VG-50 or Adrienne AEC-Box-28
LTC G enerator Horita TG-50 or Adrienne AEC-Box-28
NTSC to SDI C onverter Grass Valley 8960DEC or AJA model
D5D
RCA to 15 pin header custom c able
15-pin male Dsub connector, Tektronix
part number 131-1164-00, RCA plug
Allied 932-1098, and wire. (See Figure 2.)
VGA to 5x BNC adapter cable 15 pin VGA connector input, 5 BNC
connector outputs
Tektronix part number 174-5126-00
1 to 2 VDC voltage source (Required for
Option CPS)
1.5 V battery or power supply
BNC to retractable hook tip (Required for
Option CPS)
Tektronix part number 013-0076-01
BNC barrel connector
3 Gb/s test signal source Tektronix WFM7120 with Option JIT
Option JIT includes test signal generation
capability
3 Gb/s c lone cable Simulate 10 to 150 meters of 1694A
equivalent in 10 m steps
Faraday FFE Kit
1
The required custom signals are provided on the User Documents CD. These signals are also provided for an AVG1 module, if an 067-0465-00 (AVC1) is not
available. Download the P VCustomSignals.zip file, unzip it, and install the signals on your TG2000.
2
Note that the 067-0465-00 (AVC1) is not available outside of Tektronix. Other equipment can be substituted but it might not have sufficient accuracy to
guarantee the specifications. For hum insertion, a general-purpose sine wave generator can be used to terminate and drive back into the video signal
through appr opriate impedance m atching.
82 Waveform Monitors Specifications and Performance Verification
