Tektronix WFM7020 Technical Reference

Specifications
Table 48: Supported Standards (cont.)
Image system number for indicated field/frame rate
Image System Interface Signal Type 60 59.94 50 30 29.97 25 24 23.98
10-bit 4:4:4(:4)
R’G’B’ (A)
XXXXX
12-bit 4:4:4 R’G’B’
XXXXX
10-bit 4:4:4(:4)
Y’C’
B
C’
R
(A)
XXXXX
12-bit 4:4:4 Y’C’
B
C’
R
XXXXX
274M 2048 x
1080/P,
PsF
372M-
propsed
12-bit 4:2:2(:4)
Y’C’
B
C’
R
(A)
XXXXX
295M
(1250/50)
1920 x
1080/I, P
Not supported
240M
260M
1920 x
1035/I
292M
4:2:2 Y’C’
B
C’
R
XX
296M 292M
4:2:2 Y’C’
B
C’
R
1234
5
6
7
8
720 x
576/I
(625)
292M
4:2:2 Y’C’
B
C’
R
XITU-R
BT.601
720 x
483/I
(525)
292M
4:2:2 Y’C’
B
C’
R
X
293M 720 x
480/P
Not supported
Alarms
The following tables lis
t the alarms that may be set for the waveform monitors.
Table 49: Common Alarms
Alarm Description
HW Fault
Indicates a system fault occurred. May require service
SDI Input Missing Indicates that no signal is detected o n the selected SDI input
SDI Input Signal Lock Indicates unable to lock to selected SDI input signal
Reference Missing Indicates that no signal is detected on the Ref input when REF EXT is selected
Ref Lock Indicates unable to lock to the Ref input signal when REF EXT is selected
Ref Fmt Mismatch Indicates that the signal format detected on Ref input differs from the configured
External Ref format
RGB Gamut Error
Indicates that the selected video input signal contains colors that violate the
configured Diamond gamut thresholds
Composite Gamut Error
Indicates that the selected video input signal contains colors that violate the
configured Arrowhead gamut thresholds
38 Waveform Monitors Specifications and Performance Verification
