Specifications
Table 3: Composite Analog Inputs A and B Physical Layer (cont.)
Characteristic Performance requirement Reference information
Video Input Crosstalk Between
Channels
≥ 60 dB to 6 MHz
Loop through Isolation ≥ 70 dB to 6 MHz
DC Offset with Restore Off, Typical
≤ 20 mV
Measured in full screen mode at X5 Gain
DC Restore Modes Fast, Slow, and Off modes
Slow has a typical bandwidth of 10 Hz Fast
has a typical bandwidth of 500 Hz
DC Restore Offset Error
≤ 2mV
Registration between back porch and
0 V graticule
DC Offset Between Inputs W ith
Restore Off
≤ 7mV
Fast Mode
> 95% attenuation
DC Restore
50 Hz and
60 Hz Attenuation
Slow Mode < 10% attenuation, < 10% peaking
Blanking Shift with 10% to 90%
APL Change
≤ 1 IRE (7 mV PAL)
Blanking Shift with Presence and
Absence of Burst
≤ 1 IRE (7 mV PAL), Typic ally 0 mV
Lock Range ± 50 ppm, remains locked
Vector typically OK to ± 80 ppm. w aveform
display typically locked to ± 200 ppm
Lock in Presence of Hum 700 mV
p-p
, on full amplitued 100% color bar
signal, remains locked
Lock in Presence of White Noise S ignal/Noise ratio of 32 dB, 5 MHz bandwidth
on black burst, remains locked
Color Framing Correct color framing detected for signals
having < 45 SCH phase error with burst
present
Table 4: Waveform Sweep (Horizontal) Deflection
Characteristic Performance requirement Reference information
Accuracy
± 0.5%, all rates Line sweeps for 1080P 60/59/50 dual link
formats are shown with image scanning time
scale. In these formats, each link operates
at
1
/
2
the image scanning rate, so link time
scale is twice the indicated time per division.
Sweep
Linearity
0.2% of time displayed on screen
Fully digital system
4 Waveform Monitors Specifications and Performance Verification
