Specifications
Table 27: Analo
g Audio Outputs
Characteristic Performance requirement Reference inform ation
Audio Modes
Balanced: provides a full-scale output of
24 dBu and is designed for professional
balanced app
lications
Unbalanced: Designed to drive the
unbalanced inputs of consumer amplifiers, in
whichcaset
he negative output pin must be
grounded
Audio Sources
The channel
s routed to the line outputs may
include: Embedded audio source, AES audio
source, Analog audio source, and Decoded
Dolby
Number of C
hannels
Provides up to eight channels
Output Co
nnections
Balanced, unterminated via rear panel
connecto
r
62 pin, 3 row, DSUB connector, but only 2
rows of 42 pins are connected
Ground n
egative output to support
unbalanced mode
Maximum Output Levels
+24 dBu ±
0.5 dBu
When one
output is grounded to achieve
unbalanced mode, the outher output will be
driven to a larger amplitude. You c an reduce
the lev
el by adding attenuation in the Audio
Settings menu. Do not exceed the maximum
rated output power in either mode
Input to Output Gain
0 dB to –120 dB in 0.5 dB steps
Digital Input to Analog Output G ain
Accu
racy over Frequency
± 0.5dB, 20 Hz to 20kHz, 0 to –40 dBFS , 20
or 24
bit input
Anal
og Input to Analog Output
Gain Accuracy over Frequency
± 0.8dB, 20 Hz to 20 kHz, 24dBu to –16dBu
Output Impedance 50 Ω
Intended to drive ≥600 Ω load. Drivers
are
capable of driving a minimum load
impedance of 300 Ω but may overheat. DO
NOT exceed maximum rated output power
Digital Input to Analog Output
Di
stortion (THD + N)
≤–0.01% from full scale to –20 dBFS,
20
Hz to 20 kHz
A
nalog Input to Analog Output
Distortion (THD + N)
≤
–0.02% from full scale to –20 dBFS,
20 Hz to 20 kHz
Digital Input to Analog Output
Crosstalk, Typical
<–90 dB, 20 Hz to 20 kHz, 24 dBu or 0 dBFS
input
<–100 dB, 20 Hz to 2 k Hz, 24 dBu or 0 dBFS
input
Defined as cross talk within a pair
Waveform Monitors Specifications and P erformance Verification 25
