Specifications
Table 16: Picture Mode (cont.)
Characteristic Performance requirement Reference information
Pix Border On/Off
Allows user to mask or show the inactive
portions of the raster such as ANC area for
digital and sync for analog.
When the border is on, the image is scaled to
correct the aspect ratio. W hen the border is
off, the image is either mapped pixel to pixel
(full screen SD), or minimally decimated to
reduce the atrifacts
Synchronization
Picture mode always uses internal timing; it
is not affected by external sync
Aspect Ratio
Allows choice of 16:9 or 4:3 for SD, to
support widescreen
Table 17: Signal Level / Cable Length Detector
Charac
teristic
Perfor
mance requirement
Refere
nce information
Cable L
ength Measurement Error
15m ± 10
% for cable types listed at end of
table
Requir
es clean SD signal with rise time
<1 ns for full accuracy. Excessive ringing or
slower rise time may appear as increased
cable
length
Cabl
e Length Measurement
Resolution
2 meters, nominal
Cable Length Measurement
Range, Typical
Cable loss range of 0 to 30 dB at
1
/
2
serial
bit rate
Typ
ically runs to 40 dB, but with reduced
accuracy
Equivalent to 0 to 300 m Belden 8281 for SD,
0to
120 m Belden 8281 for HD
Launch Amplitude Measurement
Ac
curacy, Typical
± 40 mV at 800 mV level, 0 to 100 m Belden
82
81 cable
Launch Amplitude Measurement
Re
solution, Typical
10 mV
Launch Amplitude Measurement
D
ynamic Range, Typical
±
50% from 800 mV
C
able Types
B
elden 1694A/1505A/8281/1855A Canare
L-5CFB Image 1000
Cable loss measurement
Displays loss around 160 MHz minus loss
around 18 MHz
16 Waveform Monitors Specifications and Performance Verification
