Tektronix WFM7020 Technical Reference

Incoming Inspection
Table 61: Required Test Equipment (cont.)
Test Equipm ent Requirements Example
NTSC Black Tektronix TG2000 with BG1 and additional
modules indicated in the next three rows
1080i 59.94 HD signals required for
WFM7120 or WFM7020 with Option HD:
100% color bars
10-bit shallow ramp
SDI Matrix Split Field Pathological Signal
100% sweep
HDVG1 module for TG2000 (Embedded
audio needed for audio options AD, DS,
DDE)
525/270 SD signals required:
100% color bars
10-bit shallow ramp
SDI Matrix Split Field Pathological Signal
100% sweep
DVG1 module for TG2000 (Embedded
audio needed for audio options AD, DS,
DDE)
Composite signals required for Option
CPS:
NTSC SMPTE bars
AVG1 module for TG2000
Dual link signals required for Option DL TG700 with HDLG7 module
SDI serial digital video test generator,
with embedded audio and composite
signal source
AV Delay
TG700 with DVG7 module
AES Audio Signal Generator
48 kHz, 24 bit w ord length signals
Rohde & Schwarz UPL06, Tektronix
AM700 and AM70.
AES Audio Signal Analyzer Rohde & Schwarz UPL06, Tektronix
AM700.
Analog Audio S ignal Generator Rohde & Schwarz UPL06, Tektronix
AM700 and AM70.
Waveform Monitor Used to test SDI Pixmon output
Tektronix WFM7120 or WFM700
Video Test Signals SDI 525 10-bit shallow ramp
SDI 525 100% sweep
NTSC black
NTSC SMPTE bars
Provided by Tektronix TG2000 as
specified above
LT C generator Horita TRG-50 or Adrienne AEC-Box-28
Voltmeter F luke 87 or equivalent
15-pin Dsub male connector and cable Used to mate with the ground closure port
(See Figure 2 on page 94.)
Computer and Ethernet cable
Used to test Ethernet connection
Generic equipment
Dual Link Generator Tektronix T G700
3 Gb/s HD SDI signal source
Tektronix W FM7120 with test signal
capability (included with Option JIT)
Waveform Monitors Specifications and P erformance Verification 59
