Tempest900 2-Channel Operating Manual
6- Local Area Network (LAN) RJ-45 Connector
The Local Area Network (LAN) RJ-45 Connector is used to connect the Tempest BaseStation to a user supplied PC running Tempest Desktop
Conguration (T-Desk®) software. The user can then monitor and/or adjust BaseStation and BeltStation settings via the PC interface. This
connection can be made directly or through a Local Area Network (LAN). See the separate T-Desk Operating Manual for more information.
7- Relay Connector
The Relay Connector provides access to all of the relay closure contacts for the Tempest BaseStation. There are six relays including one common
Stage Announce relay and ve individually assignable relays - one for each of the wireless BeltStations. See the section on “GPO Relay Contacts.
8- Antenna Connector
The Antenna Connector is used to connect the antenna to the Tempest BaseStation. The Antenna Connector is an RP-TNC (Reverse Polarized-
TNC) connector. Cables used to attach to this Antenna Connector must be properly terminated with mating RP-TNC connectors and the proper
cable type.
9- Remote Transceiver RJ-45 Connector
The Tempest Remote Transceiver RJ-45 connector is used to connect the optional remote transceiver to the Tempest BaseStation. The remote
transceiver can be located up to 1,500 feet from the BaseStation.
